| Place of Origin: | CHINA |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | NFP-2 |
| Minimum Order Quantity: | 1 SET NFPA 701 Part 2 Large Scale Flammability Test Equipment |
| Price: | negotiable |
| Packaging Details: | NFPA 701 Part 2 Large Scale Flammability Test Equipment packed in Plywood case |
| Delivery Time: | 40 days |
| Payment Terms: | Western Union, T/T, L/C |
| Supply Ability: | 200 sets per month |
| Test Standard: | NFPA 701 Part 2 Large Scale Fire Test | Chamber Size: | 350mm (W) X 2050mm X (H) X 350mm (D) |
|---|---|---|---|
| Weight: | 51KG | Power Supply: | 110 To 230 V, 50HZ |
| Gas: | Methane | Keyword: | NFPA 701 Flammability Test Equipment |
| Material: | Stainless Steel | Warranty: | 1 Year |
| Highlight: | Large Scale Flammability Test Equipment,Flammability Test Equipment For Films,NFPA 701 Part 2 |
||
Introduction
NFPA 701 is Standard Methods of Fire Tests for Flame Propagation of Textiles and Films. According to different fabric weight, divided into 1 methods and methods 2.
Features
1.NFPA 701 Part 2 Large Scale Flammability Test Equipment is specified apparatus for all hanging decorative materials weighing not less than 21 oz/yd² (700 g/m²).
2.Stainless steel test cabinet with glass observation panel.
3.25°angle Bunsen burner with automatic timer to preset ignition time and record after-flame.
4.Gas system include the flow meter, pressure meter and pressure reducing valve.
5.Specimen holder included.
Installation Requirements
1.Electric:110 to 230 V, 50HZ
2.Ambient Temperature: Operating 21°C
3.Gas: Methane
4.Dimension:350mm (W) x 2050mm x (H) x 350mm (D)
5.Weight:51KG
Photos of NFPA 701 Part 1 Fire Test Equipment for Textile nand Films
