| Place of Origin: | CHINA |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | AIC22057 |
| Minimum Order Quantity: | 1 Set Double-head Skiving Machine |
| Price: | Negotiable |
| Packaging Details: | Double-head Skiving Machine is packed in plywood case |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100 sets per month |
| Test Standard: | IEC 60811-1-1 | Grinding Wheel Speed: | 8.6m/s |
|---|---|---|---|
| Sample Size: | 260×36×8mm | Stroke: | 20mm |
| Dimension: | 500mm×400mm×315mm | Weight: | 80KG |
| Power Supply: | 380V,2A | Color: | White |
| Highlight: | Skiving Machine,IEC 60811-1-1,Skiving Machine for Rubber |
||
Product description:
The double head skiving machine is specially designed for rubber factories and research institutions to grind rubber test pieces to a certain thickness for other testing equipment to conduct tests. It is one of the essential equipment in the inspection of rubber quality.
The Skiving machine is mainly composed of main components such as the base feed carriage, working wheel, motor, grinding wheel, etc.
The Skiving machine has a grinding wheel and a drag plate added to the left, forming two types of grinding wheels, coarse and fine, working simultaneously, with the characteristic of one machine for both purposes. This product is easy to use, saves time, improves work efficiency, and is safe and reliable.
Standard:
• GB/T 2951.11-2008
• IEC 60811-1-1: 2001
Technical parameters:
| 1 | Grinding wheel speed | 8.6m/s |
| 2 | Grinding wheel |
C-30-P-4-V, φ150* φ32* φ45mm 1100 rpm C-60-P-4-V, φ150* φ32* φ45mm 1100 rpm |
| 3 | Sample size | 260×36×8mm |
| 4 | Working wheel stroke | 20mm |
| 5 | Overall dimensions | 500mm×400mm×315mm |
| 6 | Weight | 80KG |
| 7 | Power Supply | 380V, 2A |
